Arm Ethos-U85 NPU: Unlocking Generative AI at the Edge with Small Language Models

As artificial intelligence evolves, there is increasing excitement about executing AI workloads on embedded devices using small language models (SLM).

Arm’s recent demo, inspired by Microsoft’s “Tiny Stories” paper and Andrej Karpathy’s TinyLlama2 project, where a small language model trained on 21 million stories generates text, showcases endpoint AI’s potential for IoT and edge computing. In the demo, a user inputs a sentence, and the system generates an extended children’s story based on it.

Our demo featured Arm’s Ethos-U85 NPU (Neural Processing Unit) running a small language model on embedded hardware. While large language models (LLMs) are more widely known, there is growing interest in small language models due to their ability to deliver solid performance with significantly fewer resources and lower costs, making them easier and cheaper to train.

Implementing A Transformer-based Small Language Model on Embedded Hardware

Our demo showcased the Arm Ethos-U85 as a small, low-power platform capable of running generative AI, highlighting that small language models can perform well within narrow domains. Although TinyLlama2 models are simpler than the larger models from companies like Meta, they are ideal for showcasing the U85’s AI capabilities. This makes them a great fit for endpoint AI workloads.

Developing the demo involved significant modeling efforts, including the creation of a fully integer int8 (and int8x16) Tiny Llama2 model, which was converted to a fixed-shape TensorFlow Lite format suitable for the Ethos-U85’s constraints.

Our quantization approach has shown that fully integer language models can successfully balance the tradeoff between maintaining strong accuracy and output quality. By quantizing activation, normalization functions, and matrix multiplications, we eliminated the need for floating-point computations, which are more costly in terms of silicon area and energy—key concerns for constrained embedded devices.

The Ethos-U85 ran a language model on an FPGA platform at only 32 MHz, achieving text generation speeds of 7.5 to 8 tokens per second—matching human reading speed—while using just a quarter of its compute capacity. In a real system-on-chip (SoC), performance could be up to ten times faster, significantly enhancing speed and energy efficiency for AI processing at the edge.

The children’s story-generation feature used an open-source version of Llama2, running the demo on TFLite Micro with an Ethos-NPU back-end. Most of the inference logic was written in C++ at the application level. Adjusting the context window enhanced narrative coherence, ensuring smooth, AI-driven storytelling.

The team’s adaptation of the Llama2 model to run efficiently on the Ethos-U85 NPU required careful consideration of performance and accuracy due to the hardware limitations. Using mixed int8 and int16 quantization demonstrates the potential of fully integer models, encouraging the AI community to optimize generative models for edge devices and expand neural network accessibility on power-efficient platforms like the Ethos-U85.

Showcasing the Power of the Arm Ethos-U85

Scalable from 128 to 2048 MAC units (multiply-accumulate units), the Ethos-U85 achieves a 20% power efficiency improvement over its predecessor, the Ethos-U65. A standout feature of the Ethos-U85 is its native support for transformer networks, which earlier versions could not support.

The Ethos-U85 enables seamless migration for partners using previous Ethos-U NPUs, allowing them to capitalize on existing investments in Arm-based machine learning tools. Developers are increasingly adopting the Ethos-U85 for its power efficiency and high performance.

The Ethos-U85 can reach 4 TOPS (trillions of operations per second) with a 2048 MAC configuration in silicon. In the demo, however, a smaller configuration of 512 MACs on an FPGA was used to run the Tiny Llama2 small language model with 15 million parameters at just 32 MHz.

This capability highlights the potential for embedding AI directly into devices. The Ethos-U85 effectively handles such workloads even with limited memory (320 KB of SRAM for caching and 32 MB for storage), paving the way for small language models and other AI applications to thrive in deeply embedded systems.

Bringing Generative AI to Embedded Devices

Developers need better tools to navigate the complexities of AI at the edge, and Arm is addressing this with the Ethos-U85 and its support for transformer-based models. As edge AI becomes more prominent in embedded applications, the Ethos-U85 is enabling new use cases, from small language models to advanced vision tasks.

The Ethos-U85 NPU delivers the performance and power efficiency required for innovative, cutting-edge solutions. Like the “Tiny Stories” paper, our demo represents a significant advancement in bringing generative AI to embedded devices, demonstrating the ease of deploying small language models on the Arm platform.

Arm is opening new possibilities for Edge AI across a wide range of applications, positioning the Ethos-U85 to power the next generation of intelligent, low-power devices.

Read how Arm is accelerating real-time processing for edge AI applications in IoT with ExecuTorch.
